820 pF Space Grade Ceramic Capacitor

SKU: 20HS21N821KC

Space Qualified Capacitor by KEMET (89 more products)

Note : Your request will be directed to KEMET.

20HS21N821KC Image

The 20HS21N821KC from KEMET is a Space Qualified Capacitor with a capacitance of 820 pF and has a capacitance tolerance of ± 20%. This ceramic capacitor has a rated DC voltage of 2000 V and a surge current of 30 mA. It is designed with the C0G and X7R dielectric that features a maximum of 125°C operating temperature and is screened to MIL-PRF-49467. The capacitor has a lead spacing of 5.59 mm and measures 0.320 x 0.280 x 0.250 Inches (L x H x T). It is ideal for aerospace engine compartments, switch mode power supplies, DC/DC converters, measuring equipment, inverters and high-voltage coupling applications.

Product Specifications

Product Details

  • Part Number
    20HS21N821KC
  • Manufacturer
    KEMET
  • Description
    820 pF Space Grade Ceramic Capacitor

General Parameters

  • Capacitor Type
    Ceramic Capacitor
  • Space Standard
    MIL-PRF-49467
  • Capacitance
    820 pF
  • Voltage
    2000 V
  • Surge Current
    30 mA
  • Dielectric Material
    BP C0G (NP0)
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Radially Leaded
  • RoHS Complaint
    Yes
  • Termination
    Lead (SnPb)
  • Form Factor
    HS21
  • Dimension
    0.320 x 0.280 x 0.250 Inches (L x H x T)
