8 GHz to 14 GHz, Low Noise Amplifier

SKU: ADL8143

RF Amplifier by Analog Devices
44 more products
Download Datasheet Request Information

Note : Your request will be directed to Analog Devices.

The ADL8143 from Analog Devices is a RF Amplifier with Frequency 8 to 14 GHz, Gain 26.5 to 28.5 dB, Noise Figure 1 to 1.1 dB, P1dB 0.004 to 0.007 W, IP2 14 to 22.5 dBm. Tags: Surface Mount, Low Noise Amplifier. More details for ADL8143 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    ADL8143
  • Manufacturer
    Analog Devices
  • Description
    8 GHz to 14 GHz, Low Noise Amplifier

General Parameters

  • Type
    Low Noise Amplifier
  • Configuration
    IC/MMIC/SMT
  • Frequency
    8 to 14 GHz
  • Gain
    26.5 to 28.5 dB
  • Noise Figure
    1 to 1.1 dB
  • P1dB
    0.004 to 0.007 W
  • IP2
    14 to 22.5 dBm
  • IP2
    0.025 to 0.178 W
  • IP3
    19.5 to 22 dBm
  • IP3
    0.089 to 0.158 W
  • Saturated Power
    0.008 to 0.01 W
  • Industry Application
    SATCOM
  • Input Power
    20 dBm
  • Input Power
    0.1 W
  • PAE
    15.53 to 19.91%
  • Impedance
    50 Ohms
  • Return Loss
    11 to 19 dB
  • Input Return Loss
    11 to 17 dB
  • Output Return Loss
    15 to 19 dB
  • P1dB
    5.5 to 8.5 dBm
  • Supply Voltage
    1.2 to 3.5 V
  • Power Dissipation
    0.95 W
  • Quiscent Current
    35 mA
  • Package Type
    Surface Mount
  • Package
    8-Lead Lead Frame Chip Scale Package [LFCSP]
  • Pulsed/CW
    CW
  • Dimensions
    2 x 2 mm
  • Saturated Power
    9 to 10 dBm
  • Operating Temperature
    -55 to 125 Degree C
  • Storage Temperature
    -65 to 150 Degree C
  • Standard
    Commercial Space Low (CSL)
  • Standards Supported
    LEO
