Power Amplifier from 5.9 to 9.5 GHz

SKU: XP1035-QH

RF Amplifier by MACOM
35 more products
Download Datasheet Request Information

Note : Your request will be directed to MACOM.

The XP1035-QH from MACOM is a RF Amplifier with Frequency 5.9 to 9.5 GHz, Small Signal Gain 26 dB, P1dB 0.562 W, IP3 39 dBm, IP3 7.94 W. Tags: Surface Mount, Power Amplifier. More details for XP1035-QH can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    XP1035-QH
  • Manufacturer
    MACOM
  • Description
    Power Amplifier from 5.9 to 9.5 GHz

General Parameters

  • Type
    Power Amplifier
  • Frequency
    5.9 to 9.5 GHz
  • Small Signal Gain
    26 dB
  • P1dB
    0.562 W
  • IP3
    39 dBm
  • IP3
    7.94 W
  • Saturated Power
    0.79 W
  • Industry Application
    SATCOM
  • Input Power
    15 dBm
  • Input Power
    0.031 W
  • Reverse Isolation
    45 dB
  • Return Loss
    10 to 13 dB
  • Input Return Loss
    13 dB
  • Output Return Loss
    10 dB
  • P1dB
    27.5 dBm
  • Supply Voltage
    5 to 8 V
  • Power Dissipation
    4.2 W
  • Current Consumption
    70 to 280 mA
  • Transistor Technology
    pHEMT
  • Technology
    GaAs
  • Package Type
    Surface Mount
  • Pulsed/CW
    CW
  • Saturated Power
    29 dBm
  • Operating Temperature
    -55 to 85 Degree C
  • Storage Temperature
    -65 to 165 Degree C
  • RoHS
    Yes
  • Standards Supported
    VSAT
  • Sub-Category
    Linear Amplifier
  • Application
    Point-to-Point, Radio
