CMA-252LN+

RF Amplifier by Mini Circuits (7 more products)
Download Datasheet Request Information

Note : Your request will be directed to Mini Circuits.

CMA-252LN+ Image

The CMA-252LN+ from Mini Circuits is a RF Amplifier with Frequency 1.5 to 2.5 GHz, Gain 16.8 dB, Noise Figure 1 dB, P1dB 0.06 W, IP3 30 dBm. Tags: Surface Mount, Low Noise Amplifier. More details for CMA-252LN+ can be seen below.

Product Specifications

Product Details

  • Part Number
    CMA-252LN+
  • Manufacturer
    Mini Circuits

General Parameters

  • Type
    Low Noise Amplifier
  • Configuration
    IC/MMIC/SMT
  • Application
    Base Station
  • Frequency
    1.5 to 2.5 GHz
  • Gain
    16.8 dB
  • Noise Figure
    1 dB
  • P1dB
    0.06 W
  • IP3
    30 dBm
  • IP3
    1 W
  • Input Power
    20 to 25 dBm
  • Input Power
    0.316 W
  • Impedance
    50 Ohms
  • Input VSWR
    1.50:1
  • Output VSWR
    1.30:1
  • Input Return Loss
    11.1 to 19 dB
  • Output Return Loss
    7.1 to 26 dB
  • Supply Voltage
    4 VDC
  • Current Consumption
    57 mA
  • Transistor Technology
    E-PHEMT
  • Package Type
    Surface Mount
  • Space Qualified
    On Request
  • RoHS
    Yes
