L-Band GaAs Low Noise Amplifier

SKU: CHA3801-FAB

Note : Your request will be directed to United Monolithic Semiconductors.

CHA3801-FAB Image

The CHA3801-FAB from United Monolithic Semiconductors is a RF Amplifier with Frequency 1 to 2 GHz, Gain 28 dB, Gain Flatness 1 dB, Noise Figure 1.5 dB, Output Power 16 dBm. Tags: Surface Mount, Low Noise Amplifier. More details for CHA3801-FAB can be seen below.

Product Specifications

Product Details

  • Part Number
    CHA3801-FAB
  • Manufacturer
    United Monolithic Semiconductors
  • Description
    L-Band GaAs Low Noise Amplifier

General Parameters

  • Type
    Low Noise Amplifier
  • Application
    Military, Commercial, Communication Systems, Space Qualified
  • Frequency
    1 to 2 GHz
  • Gain
    28 dB
  • Gain Flatness
    1 dB
  • Noise Figure
    1.5 dB
  • Output Power
    16 dBm
  • Output Power
    0.03 W
  • P1dB
    0.03 W
  • IM3
    27 dBm
  • Saturated Power
    0.05 W
  • Reverse Isolation
    45 dB
  • Input Return Loss
    -15 dB
  • Output Return Loss
    -15 dB
  • Space Heritage
    Yes
  • Supply Voltage
    5 V (Drain Voltage)
  • Current Consumption
    70 mA
  • Transistor Technology
    pHemt
  • Technology
    GaAs
  • Package Type
    Surface Mount
  • Package
    Hermatic, SMD Leadless
  • Space Qualified
    Yes
  • Operating Temperature
    -40 to 85 Degree C
  • Storage Temperature
    -55 to 150 Degree C
  • RoHS
    Yes
  • Note
    Drain Current : 50 to 100 mA
