L-Band RHCP Wideband Omni Antenna

SKU: PW1516-100

Satellite Antenna by PlaneWave
32 more products
Download Datasheet Request Information

Note : Your request will be directed to PlaneWave.

PW1516-100 Image

The PW1516-100 from PlaneWave is a Satellite Antenna with Frequency Range Tx : 1.62 to 1.675 GHz, Rx : 1.513 to 1.565 GHz, Tx Frequency 1.62 to 1.675 GHz, Rx Frequency 1.513 to 1.565 GHz, Antenna Gain 4 to 6 dBi, Power Consumption 10 W. More details for PW1516-100 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    PW1516-100
  • Manufacturer
    PlaneWave
  • Description
    L-Band RHCP Wideband Omni Antenna

General Parameters

  • Antenna Type
    Flat Panel Antenna
  • Frequency Band
    L Band
  • Frequency Range
    Tx : 1.62 to 1.675 GHz, Rx : 1.513 to 1.565 GHz
  • Tx Frequency
    1.62 to 1.675 GHz
  • Rx Frequency
    1.513 to 1.565 GHz
  • Antenna Gain
    4 to 6 dBi
  • Polarization
    RHCP
  • Power Consumption
    10 W
  • Directionality
    Omni-Directional
  • Axial Ratio
    2 to 8 dB
  • VSWR
    2.00:1
  • Mass
    190 g
  • Connector
    SMA, SMA - Female
  • Operating Temperature
    -70 to 100 Degree C
  • Storage Temperature
    -70 to 100 Degree C
  • Space Standard
    GSFC-STD-7000
  • Application
    Data
  • Dimension
    3.8 x 3.8 x 0.72 In
