Reaction Wheels

82 Reaction Wheels for Space Applications from 23 manufacturers listed on SatNow

Reaction Wheels for space applications from multiple manufacturers are listed on SATNow. Use the filters to select products based on your requirement. View product details, download datasheets, compare products, get quotes and pricing for matching products. SATNow has compiled this list of products specifically for Space and Satellite Applications.

Description:Low Mass, Low Power Reaction Control Wheel, Which Allows Cubesats And Other Small Platforms To Control Their Attitude.
Satellite Type:
CubeSat
Torque:
±8 to 12 mN.m (Braking)
Angular Momentum:
0.015 Nms, 0.03 Nms, 0.05 Nms
Mass:
0.197 Kg, 0.21 Kg, 0.375 Kg
Speed:
5000 rpm
Static Imbalance:
g-cm
Dynamic Imbalance:
g-cm2
Supply Voltage:
4.5 to 5.25 V
Power Consumption:
1.9 W
Space Heritage:
Yes
Operating Temperature:
-40 to 60 Degree C
Interface:
RS-422, RS-485
more info
Description:Separate wheel drive electronics (WDE) for up to four Reaction Wheels
Satellite Type:
CubeSat
Torque:
23 Nm
Angular Momentum:
5.8 Nms
Mass:
2400 Kg
Speed:
8000 to 16, 380 rpm
Operating Temperature:
-20 to 50 Degree C
more info
Description:Reaction Wheel With Integrated Fibre Optical Gyro For Small Satellites
Satellite Type:
SmallSat
Torque:
14.2 to 16 mNm
Angular Momentum:
0.5 Nms
Mass:
1.55 (RW + WDE), 1.70 (RW + WDE + Gyro)
Speed:
500 to 5000 rpm
Supply Voltage:
5 (Electronics), 17 to 32 V (Motor)
Power Consumption:
0.5 W
Space Heritage:
Yes
Storage Temperature:
-30 to 50 Degree C
Operating Temperature:
-20 to 40 Degree C
Interface:
UART, RS-422
more info
Description:Reaction wheels an autonomous actuators of four flywheels with drivers integrated into 3U or larger nanosatellite
Satellite Type:
NanoSat, CubeSat, SmallSat
Torque:
0.64 to 1.2 mNm
Angular Momentum:
0.0068 Nms, 0.025 Nms
Mass:
0.52 Kg
Speed:
±6000 rpm
Vibration:
12 g RMS
Supply Voltage:
5 to 14 V
Power Consumption:
2 W
Storage Temperature:
-50 to 105 Degree C
Operating Temperature:
-30 to 85 Degree C
Interface:
CAN
more info
Description:Integral 4 Reaction Wheels Redundant 3-Axis Control System, Enabling Precision Pointing Of The Small Satellite
Satellite Type:
CubeSat
Torque:
3.2 mNm, 2.5 to 5.9 mNm (4RW)
Angular Momentum:
0.02 Nms, 0.0156 Nms, 0.037 Nms
Mass:
0.137 Kg, 0.665 Kg (4RW)
Speed:
6500 rpm
Supply Voltage:
5 V
Power Consumption:
0.15 W, 0.6 W (4RW)
Operating Temperature:
-40 to 85 Degree C
Interface:
SPI, UART
more info
Description:The Bradford Reaction Wheel Unit (RWU) channel consists of a Reaction Wheel Assembly (RWA) and one Wheel Drive Electronics Box (WDE).
Torque:
248 mNm
Angular Momentum:
45 Nms
Mass:
7.45 Kg
Speed:
4000 rpm
Vibration:
IP: 10 g RMS, OoP: 15 g RMS (RWA), IP: 11.2 g RMS,...
Static Imbalance:
0.5 g-cm
Dynamic Imbalance:
9 g-cm2
Supply Voltage:
28 to 50 V
Power Consumption:
7.6 W (Quiescent Power), 29 W (Steady State Power)...
Space Heritage:
Yes
Operating Temperature:
-15 to 60 Degree C (RWA), -30 to 60 Degree (WDE)
more info
Description:0.015 Nms Angular Momentum Reaction Wheels with advanced lubrication system for long life and vibration isolation
Torque:
4 mNm
Angular Momentum:
0.015 Nms
Mass:
0.13 Kg
Supply Voltage:
10 to 14 V
Power Consumption:
1 W
Space Heritage:
Yes
Interface:
RS-422
more info
Description:Satellite Reaction Wheel With small size that Allows to control the attitude of your satellite
Satellite Type:
CubeSat
Torque:
0.23 mNm
Angular Momentum:
0.00177 Nms
Mass:
0.06 Kg
Speed:
8000 rpm
Vibration:
14 g RMS
Static Imbalance:
0.003 g-cm
Dynamic Imbalance:
0.005 g-cm2
Supply Voltage:
3 to 16 V
Power Consumption:
0.15 W (Average Power), 0.65 W (Peak Power)
Operating Temperature:
-10 to 60 Degree C
Interface:
I2C, UART, CAN
more info
Description:Vacuum-Lubricated Reaction Wheels Are Designed For Picosatellites, Nanosatellites And Microsats
Satellite Type:
NanoSat, MicroSat, PicoSat
Torque:
±1 mNm
Angular Momentum:
0.01 Nms (Nominal), 0.018 Nms (Peak)
Mass:
0.120 Kg
Vibration:
12 g RMS
Supply Voltage:
3.4 to 6 V
Power Consumption:
1.05 W
Space Heritage:
Yes
Operating Temperature:
-40 to 70 Degree C
Interface:
UART, I2C, SMBus
more info
Description:0.2 Nms Angular Momentum Reaction Wheels for Satellite Constellations
Torque:
±20 mNm
Angular Momentum:
0.2 Nms
Mass:
1 Kg
Speed:
±6000 rpm
Vibration:
22 g RMS random 3 axis
Static Imbalance:
0.1 g-cm
Dynamic Imbalance:
8 g-cm2
Supply Voltage:
9 to 36 V
Power Consumption:
45 W
Space Heritage:
Yes
Storage Temperature:
-40 to 80 Degree C
Operating Temperature:
-20 to 70 Degree C
Interface:
RS-422, RS-485, CAN
more info

What are Reaction Wheels?

Reaction wheels or momentum wheels are flywheels that are used to provide attitude (orientation) control and stability to a spacecraft. There is no air resistance in space and as a result when a reaction wheel turns in one direction the spacecraft tends to turn in the opposite direction as per Newton’s Third Law. Therefore, by maintaining the rotation of one reaction wheel, a single axis of the spacecraft is stabilized and with a minimum of three wheels that are spinning in three directions.

The reaction wheels are fixed in place they spin at a very high rate of revolution which is around 1000-4000 revolutions per minute, which builds up angular momentum. Therefore, to change the orientation of the spacecraft the rate at which the wheel spin can be changed. As a result, this rate of change produces a torque that causes the spacecraft/satellite to change its direction. The main advantage of the technology of reaction wheels is that it works on electricity alone which means that there is no need for the use of liquid propellant to change the direction of the spacecraft.
