Weekly Edition
Date: May 23, 2024

Featured Space and Satellite Products this Week
Space Qualified Inductor
0.22-47.0 µH Outgassing Compliant Power Inductors
Space Qualified Inductor  from Coilcraft

The AE526PGA from Coilcraft are Space-Qualified Inductors with an inductance range of 0.22-47 µH and an inductance tolerance of +/- 20 %. These inductors have a DC resistance of 1.1-107 ohms and a saturation current of 1.6-38 A. They have a self-resonant frequency range of 4-125 MHz and an RMS current of 2.0-21.8 A. The inductors feature tin-lead (Sn-Pb) termination for the best possible board adhesion and have passed NASA low outgassing specifications.
Download Datasheet Product Details
SATCOM Antenna
Folding X-Wing SATCOM-On-The-Move Antenna
SATCOM Antenna  from ARA

The ARA-0548FM from ARA is a SATCOM Antenna with a frequency range of 225-400 MHz. This UHF SATCOM antenna has a gain of 8 dBic and an impedance of 50 Ohms. It is right-hand circular or linear vertical polarized and has a VSWR of 1.5:1. The antenna has a minimum isolation of 24 dB and a maximum axial ratio of 2 dB. It has a power handling capacity of 200 W CW. The antenna supports N-female and TNC-female connectors and weighs 3.13 lbs.
Download Datasheet Product Details
Space Qualified Optocoupler
Hermetically Sealed 3.3 V High Gain Optocoupler
Space Qualified Optocoupler  from Broadcom

The ACPL-6751L from Broadcom is a Space Qualified Optocoupler with a forward voltage range of 1-1.8 V and an insulation leakage current of 1 µA. It has a low output saturation voltage of 0.11 V and a low input current requirement of 0.5 mA. It is designed for telephone ring detection, microprocessor system interface, voltage level shifting, line receivers, system test equipment isolation, process control input/output isolation, military, and aerospace applications.
Download Datasheet Product Details
Space Qualified RF Filter
4.25-10.00 GHz High Pass Filter for Transmitters
Space Qualified RF Filter  from Mini Circuits

The HFCN-3800 from Mini Circuits is a Space Qualified RF Filter with a frequency range of 4250-10000 MHz. This high pass filter has a stop band rejection loss of 20-30 dB and a pass band insertion loss of 1.5-2 dB. It has a stop band VSWR of 20:1 and a pass band VSWR of 1.5:1. It has a frequency cut-off of 3 dB at 3.8 GHz and a maximum RF power input handling capacity of 7 W. It is suitable for applications such as sub-harmonic rejection and transmitters/receivers.
Download Datasheet Product Details
Satellite Beacon Receiver
VSAT Satellite Beacon Receiver
Satellite Beacon Receiver  from C-COM

The BR-400L from C-COM is a Satellite Beacon Receiver with an input frequency range of 950-2200 MHz and a pre-detection bandwidth of +/- 100 kHz. It has a frequency tuning range of 10 KHz steps. This VSAT beacon receiver has a phase noise value of -97 dBc/Hz at 10 kHz and an input power level of -105 to -20 dBm. It is designed to track the power density of a satellite beacon in real-time and works seamlessly with all iNetVu controllers and antenna platforms.
Download Datasheet Product Details
Reaction Wheel
Reaction Wheel for Attitude Control in Pico Satellites
Reaction Wheel  from WITTENSTEIN cyber motor GmbH

The cyber reaction wheel 2 from WITTENSTEIN cyber motor GmbH is a Reaction Wheel with a peak torque of 0.4 mNm. This reaction wheel has a maximum rotation speed of 18000 rpm and momentum storage of 2.0 mNms. It requires an operating voltage of 3-8.8 V and has a rated power consumption of 480 mW. This compact reaction wheel measures  20 x 20 x 20 mm. It has a lifetime of 5 years and is designed for attitude control in pico or nanosatellites.
Download Datasheet Product Details
DC to DC Converter
15 V Surface Mount DC-DC Converter
DC to DC Converter  from Crane Aerospace & Electronics

The MGA2815S from Crane Aerospace & Electronics is a DC-to-DC Converter that converts an input voltage range of 16-40 V to an output voltage of 15 V. It has an output current of 333 mA and an isolation voltage of 500 Vdc. It has a ripple voltage range of 50-250 mVpp and a load/line regulation voltage range of 10-50 mV. It comes in a hermetically sealed steel case that measures 28.19 × 28.19 × 6.35 mm. It is ideal for aerospace, military, and space applications.
Download Datasheet Product Details
Block Downconverter
X-Band Low Noise Block Downconverter for SmallSats
Block Downconverter  from AmpliTech

The APT5-LNB-07750850-40K15-WR112 from AmpliTech is a Block Downconverter with an input frequency range of 7.75-8.50 GHz and an output frequency range of 800-1550 MHz. This X-band block downconverter has an LO frequency of 6.95 GHz and a minimum gain of 56 dB. The converter weighs 375 g and comes in a compact package measuring 6 x 3 x 2 inches. It is suited for smallsats, LEO, MEO, GEO, and portable or fixed X-Band teleport applications.
Download Datasheet Product Details
Star Tracker
Space Qualified Star Tracker for Small Satellites
Star Tracker  from Solar MEMS

The Star Tracker for Nano Satellites (STNS) from Solar MEMS is a Star Tracker with a field of view of 15 x 18 degrees (Rectangular). This star tracker has an exclusion HFOV of 41 degrees (Sun - Cubesat baffle) and 30 degrees (Sun - Standard baffle). It requires a supply voltage of 5 V and has a power consumption of 1 W. The star tracker weighs 160-200 g and measures 90 x 52 x 38 mm. It is ideal for attitude determination in small satellites.
Download Datasheet Product Details
Gimbal
Electric Propulsion Gimbal Thruster Assembly
Gimbal  from Moog

The Model-T 2 Phase from Moog is a Gimbal that can be configured for wide rotation on both axes with a total rotational range of +/- 36 degrees (X & Y axis). This gimbal thruster assembly has an angular resolution of 0.01125 degrees (per step). It provides vector-pointing capabilities for various propulsion thruster configurations including Xenon, Arc-jet, and NTO/MMH, and has successfully been used for orbit raising and station keeping of heavier payload satellites.
Download Datasheet Product Details
SATCOM Amplifier System
500 W DBS-Band Rack Mount High Power Amplifier
SATCOM Amplifier System  from Comtech Xicom Technology

The XTRT-500DBS from Comtech Xicom Technology is a SATCOM Amplifier System with a frequency range of 17.3-18.1 GHz. It has a maximum intermodulation of -24 dBc with two equal carriers and a phase noise of -50 dBc (AC fundamental). The amplifier system supports RS-232 and RS-422/RS-485 and ethernet T10/100 hardware interfaces. It weighs 34.02 kg. This amplifier system is designed for fixed and mobile uplink applications.
Download Datasheet Product Details
Space Qualified Power Transformer
0.97 mH Space Grade Isolation Transformer
Space Qualified Power Transformer  from Vanguard Electronics

The SIT225 from Vanguard Electronics is a Space-Qualified Power Transformer with an inductance of 0.97 mH. It is built to meet MIL-STD-981 specifications and is NASA outgassing compliant per ASTM E595. It measures 0.41 × 0.41 × 0.24 inches and is suitable for applications such as filter inductors, ripple suppressors, common mode chokes, SEPIC converters, DC/DC converters, power supplies, step-up transformers, step-down transformers, and isolation transformers.
Download Datasheet Product Details
Space Qualified Atomic Clock
Atomic Clock for Satellite Positioning Applications
Space Qualified Atomic Clock  from Leonardo

The Mini PHM from Leonardo is a Space Qualified Atomic Clock with a design life of more than 12 years in medium earth orbit. This flight-proven atomic clock has a frequency drift of less than 1x10-14 after 1 week and a frequency sensitivity of less than 1x10-15/ degree C (to temperature). It has a mass of 12 kg. It was developed for the GALILEO Next-Generation phase and is designed for precise positioning, timekeeping, and other onboard applications.
Download Datasheet Product Details
SATCOM Transceiver
16 W Ku-Band VSAT Transceiver
SATCOM Transceiver  from AnaCom, Inc

The Anasat Ku-band 16W from AnaCom is a SATCOM Transceiver with a Tx output frequency range of 13.75-14.5 GHz and an Rx input frequency range of 10.95-12.75 GHz. This transceiver has a Tx gain of 73 dB and an Rx gain of 75-100 dB. It has a 1-dB compression point of 42 dBm and a noise figure of 1-2 dB. It features built-in test facilities for improved maintainability and frequency agile radio equipment for independent Tx and Rx frequency selection.
Download Datasheet Product Details
Space Qualified Solid State Relay
DC to 1 GHz Magnetic Latching Space Grade DPDT Relay
Space Qualified Solid State Relay  from Teledyne Relays

The HRS422K from Teledyne Relays is a Space Qualified Solid-State Relay with an operating frequency range of DC to 3 GHz. This magnetic DPDT relay has a DC breakdown voltage of 100 V and an insulation resistance of 1000-10000 Mohms. It has an operating time of 2 ms. The relay has a maximum block integrity leakage current of 1 µA and a coil transient suppression of 1 Vdc. It has a mass of 2.84 g and is suitable for demanding space flight applications.
Download Datasheet Product Details
