7 V, 2.1 A Space Qualified DC to DC Converter

SKU: MFK2807D

DC to DC Converter by Crane Aerospace & Electronics
116 more products
Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

MFK2807D Image

The MFK2807D from Crane Aerospace & Electronics is a DC-to-DC Converter that converts an input voltage range of 16-50 V to an output voltage of 2-7 V. This converter delivers an output power of 21 W and has an efficiency of up to 79%. It has an out

Product Specifications

Product Details

  • Part Number
    MFK2807D
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    7 V, 2.1 A Space Qualified DC to DC Converter

General Parameters

  • Segment
    Satellite
  • Type
    Buck/Step down
  • Configuration
    Isolated
  • Number of Output
    Dual
  • Input Voltage
    16 to 50 V
  • Output Voltage 1
    7 V
  • Output Current 1
    2.1 A
  • Output Power
    21000 mW
  • Output Voltage 2
    -7 V
  • Output Current 2
    -1.5 to 1.5 A
  • Isolation Voltage
    500 Vdc
  • Efficiency
    0.81
  • Operating Temperature
    -55 to 125 Degree C
  • Industry
    Industrial, Space
  • Package Type
    Module
  • Application
    Aerospace
  • Dimension
    37.08 × 28.70 × 9.14 mm
  • Capacitance
    1000 uF
  • Regulation
    5 to 100 mV (Line), 5 to 250 mV (Load)
  • Space Standard
    MIL-PRF-38534, MIL-STD-704A
  • Standard
    MIL-PRF-38534 Class H, MIL-STD-461C CE03 and CS01 and MIL-STD-461D, E and F CE102 and CS101
  • Ripple Voltage
    70 to 80 mVpp
  • Storage Temperature
    -65 to 150 Degree C
