MFK2812S

Note : Your request will be directed to Crane Aerospace & Electronics.

MFK2812S Image

The MFK2812S from Crane Aerospace & Electronics is a DC to DC Converter with Input Voltage 16 to 50 V, Output Voltage 1 12 V, Output Current 1 2.08 A, Output Power 25000 mW, Isolation Voltage 500 Vdc. Tags: Module, Buck/Step down. More details for MFK2812S can be seen below.

Product Specifications

Product Details

  • Part Number
    MFK2812S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    12 V Single Output Buck/Step down DC to DC Converter for Low Profile Programs

General Parameters

  • Segment
    Satellite
  • Type
    Buck/Step down
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    16 to 50 V
  • Output Voltage 1
    12 V
  • Output Current 1
    2.08 A
  • Output Power
    25000 mW
  • Isolation Voltage
    500 Vdc
  • Efficiency
    0.86
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Module
  • Application
    Aerospace
  • Dimension
    37.08 × 28.70 × 9.14 mm
  • Capacitance
    2000 uF
  • Regulation
    5 to 20 mV (Line), 5 to 20 mV (Load)
  • Ripple Voltage
    35 to 100 mVpp
  • Storage Temperature
    -65 to 150 Degree C
