15 V DC-DC Converter for Aerospace Systems

SKU: MFK2815S

Note : Your request will be directed to Crane Aerospace & Electronics.

MFK2815S Image

The MFK2815S from Crane Aerospace & Electronics is a Space Qualified DC-DC Converter with a fixed frequency of 500 kHz and an output voltage of 14.70 - 15.30 V. It has an input voltage of 16-50 V and a DC isolation voltage of 500 V. This step-down converter delivers an output power of 25 W and has an efficiency of up to 87%. It has a capacitance of 2000 uF for enhancing stability and performance. It has a ripple voltage of 100 mVpp and a line and load regulation of 20 mV. This DC-DC converter has a mass of 55 g and is capable of withstanding short-term transients of up to 80 volts as per MIL-STD-704A standards. This converter has an undervoltage lockout, fully isolated magnetic feedback, and in-built short circuit protection. It is available in a hermetically sealed steel case and is designed to meet the stringent demands of satellite applications and offers optimal power conversion for a wide range of aerospace systems.

Product Specifications

Product Details

  • Part Number
    MFK2815S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    15 V DC-DC Converter for Aerospace Systems

General Parameters

  • Segment
    Satellite
  • Type
    Buck/Step down
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    16 to 50 V
  • Output Voltage 1
    15 V
  • Output Current 1
    1.67 A
  • Output Power
    25000 mW
  • Isolation Voltage
    500 Vdc
  • Efficiency
    0.87
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Module
  • Application
    Aerospace
  • Dimension
    37.08 × 28.70 × 9.14 mm
  • Capacitance
    2000 uF
  • Regulation
    5 to 20 mV (Line), 5 to 20 mV (Load)
  • Ripple Voltage
    40 to 100 mVpp
  • Storage Temperature
    -65 to 150 Degree C
