Space Qualified Buck-Boost DC-DC Converter

SKU: MFK2828S

DC to DC Converter by Crane Aerospace & Electronics
116 more products
Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

MFK2828S Image

The MFK2828S from Crane Aerospace & Electronics is a DC-DC Converter that converts an input voltage range of 16-50 V to an output voltage of 28 V. This converter is available in single and dual configurations and has full isolation with magnetic fe

Product Specifications

Product Details

  • Part Number
    MFK2828S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    Space Qualified Buck-Boost DC-DC Converter

General Parameters

  • Segment
    Satellite
  • Type
    Buck-Boost
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    16 to 50 V
  • Output Voltage 1
    28 V
  • Output Current 1
    0.89 A
  • Output Power
    25000 mW
  • Isolation Voltage
    500 Vdc
  • Efficiency
    84%
  • Operating Temperature
    -55 to 125 Degree C
  • Industry
    Industrial, Space
  • Package Type
    Module
  • Application
    Aerospace
  • Dimension
    37.08 × 28.70 × 9.14 mm
  • Capacitance
    1000 uF
  • Regulation
    150 to 280 mV (Line), 150 to 280 mV (Load)
  • Space Standard
    MIL-PRF-38534, MIL-STD-704A
  • Standard
    MIL-STD-461C CE03 and CS01 and MIL-STD-461D, E and F CE102 and CS101
  • Ripple Voltage
    80 to 200 mVpp
  • Weight
    38 g
  • Storage Temperature
    -65 to 150 Degree C
