12 V Dual DC-DC Converter for High Reliability Applications

SKU: MFL2812S

DC to DC Converter by Crane Aerospace & Electronics
116 more products
Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

MFL2812S Image

The MFL2812S from Crane Aerospace & Electronics is a DC to DC Converter with an input voltage of 28 V. This converter has an output voltage of 12 V and an output current of up to 10 A. It has an output power of up to 60 W and an output ripple of 30-100 mV p-p. The MFL converters are manufactured in a fully certified and qualified MIL-PRF-38534 facility and have an efficiency of up to 86%. The converter has a line regulation range of 0-20 mV and a load regulation of up to 20 mV. It measures 3.005 x 1.505 x 0.400 inches and is ideal for use in programs requiring high reliability, small size, and high efficiency.

Product Specifications

Product Details

  • Part Number
    MFL2812S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    12 V Dual DC-DC Converter for High Reliability Applications

General Parameters

  • Segment
    Satellite
  • Type
    Buck/Step down
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    16 to 40 V
  • Output Voltage 1
    12 V
  • Output Current 1
    5 A
  • Output Power
    60000 mW
  • Isolation Voltage
    500 Vdc
  • Efficiency
    0.86
  • Operating Temperature
    -55 to 125 Degree C
  • Industry
    Industrial, Space
  • Package Type
    Module
  • Application
    Aerospace
  • Dimension
    76.33x x 38.23 × 10.16 mm
  • Capacitance
    500 uF
  • Regulation
    0 to 20 mV (Line), 0 to 20 mV (Load)
  • Space Standard
    MIL-PRF38534
  • Standard
    MIL-PRF38534 Class H
  • Ripple Voltage
    30 to 100 mVpp
  • Storage Temperature
    -65 to 150 Degree C
