50 W Space Qualified DC-DC Converter

SKU: MFX2809S

DC to DC Converter by Crane Aerospace & Electronics
116 more products
Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

MFX2809S Image

The MFX2809S from Crane Aerospace & Electronics is a Space Qualified DC-DC Converter with an output voltage of 1-9 V. It has an input voltage of 16-50 V and a DC isolation voltage of 500 V. This step-down converter delivers an output power of 50 W

Product Specifications

Product Details

  • Part Number
    MFX2809S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    50 W Space Qualified DC-DC Converter

General Parameters

  • Segment
    Satellite
  • Type
    Buck/Step down
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    16 to 50 V
  • Output Voltage 1
    9 V
  • Output Current 1
    5560 mA
  • Output Power
    50000 mW
  • Isolation Voltage
    500 Vdc
  • Efficiency
    0.92
  • Operating Temperature
    -55 to 125 Degree C
  • Industry
    Industrial, Space
  • Package Type
    Module
  • Application
    Aerospace
  • Capacitance
    2000 uF
  • Regulation
    15 mV (Line), 30 mV (Load)
  • Space Standard
    MIL-STD-704A, MIL-PRF-38534, MIL-STD-461C, MIL-STD-461D
  • Standard
    MIL-PRF-38534 Class H, MIL-STD-461C CE03 and/or MIL-STD461D, E and F CE102
  • Ripple Voltage
    150 mVpp
  • Storage Temperature
    -65 to 150 Degree C
