15 V Surface Mount DC-DC Converter

SKU: MGA2815S

DC to DC Converter by Crane Aerospace & Electronics
116 more products
Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

MGA2815S Image

The MGA2815S from Crane Aerospace & Electronics is a DC-to-DC Converter that converts an input voltage range of 16-40 V to an output voltage of 15 V. This converter delivers an output power of 5 W and has an efficiency of up to 76%. It has an outpu

Product Specifications

Product Details

  • Part Number
    MGA2815S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    15 V Surface Mount DC-DC Converter

General Parameters

  • Segment
    Satellite
  • Type
    Buck/Step down
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    16 to 40 V
  • Output Voltage 1
    15 V
  • Output Current 1
    0.333 A
  • Output Power
    5000 mW
  • Isolation Voltage
    500 Vdc
  • Efficiency
    0.76
  • Operating Temperature
    -55 to 125 Degree C
  • Industry
    Industrial, Space
  • Package Type
    Module
  • Application
    Aerospace
  • Dimension
    28.19 × 28.19 × 6.35 mm
  • Capacitance
    300 uF
  • Regulation
    10 to 50 mV (Line), 10 to 50 mV (Load)
  • Space Standard
    MIL-PRF-38534, MIL-STD-704E, MIL-STD-461C
  • Standard
    MIL-PRF-38534 Class H
  • Ripple Voltage
    50 to 250 mVpp
  • Storage Temperature
    -65 to 150 Degree C
