12 V Dual Output DC-DC Converter for Low Profile Applications

SKU: MGH2812S

Note : Your request will be directed to Crane Aerospace & Electronics.

MGH2812S Image

The MGH2812S from Crane Aerospace & Electronics is a DC to DC Converter with an input voltage of 12-50 V an output voltage of 14.40-15.60 V. It has an output current of 100 mA and an output power of up to 1.5 W. The MGH converter is manufactured in a fully certified and qualified MIL-PRF-38534 facility and has an efficiency of up to 79%. It has a line regulation range of 80-350 mV and a load regulation range of 760-1600 mV. This converter has a capacitance of 200 µF and a ripple voltage of 50-250 mVpp. It uses a synchronization feature that is included with the converter that allows the user to match the switching frequency of the converter to the frequency of a system clock. The converter provides an undervoltage lockout and fully isolated magnetic feedback with in-built short circuit protection. It weighs 12 grams and measures 25.65 × 22.35 × 6.35 mm in dimension. The converter is ideal for use in programs requiring high reliability, small size, and high efficiency.

Product Specifications

Product Details

  • Part Number
    MGH2812S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    12 V Dual Output DC-DC Converter for Low Profile Applications

General Parameters

  • Segment
    Satellite
  • Type
    Buck/Step down
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    12 to 50 V
  • Output Voltage 1
    12 V
  • Output Current 1
    0.125 A
  • Output Power
    1500 mW
  • Isolation Voltage
    500 Vdc
  • Efficiency
    0.79
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Module
  • Application
    Aerospace
  • Dimension
    25.65 × 22.35 × 6.35 mm
  • Capacitance
    200 uF
  • Regulation
    70 to 250 mV (Line), 640 to 1400 mV (Load)
  • Ripple Voltage
    50 to 300 mVpp
  • Storage Temperature
    -65 to 150 Degree C
