4.82 to 5.18 V Dual Output Isolated DC to DC Converter

SKU: SMFLHP2805D

Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

SMFLHP2805D Image

The SMFLHP2805D from Crane Aerospace & Electronics is a DC to DC Converter with Input Voltage 19 to 40 V, Output Voltage 1 4.82 to 5.18 V, Output Current 1 0 to 16 A, Output Power 0 to 80 W, Power Consumption 15 to 25 W (Dissipation). Tags: Surface Mount. More details for SMFLHP2805D can be seen below.

Product Specifications

Product Details

  • Part Number
    SMFLHP2805D
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    4.82 to 5.18 V Dual Output Isolated DC to DC Converter

General Parameters

  • Configuration
    Isolated
  • Number of Output
    Dual
  • Input Voltage
    19 to 40 V
  • Output Voltage 1
    4.82 to 5.18 V
  • Output Current 1
    0 to 16 A
  • Output Power
    0 to 80 W
  • Power Consumption
    15 to 25 W (Dissipation)
  • Efficiency
    73 to 80%
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Surface Mount
  • Application
    Space
  • Dimension
    3.005 x 1.505 x 0.4 Inches
  • Capacitance
    500 uF
  • Frequency
    525 to 675 kHz
  • Number of Outputs
    Dual
  • Regulation
    Line : 0 to 100 mV, Load : 0 to 100 mV
  • Ripple Voltage
    25 to 150 mVpp
  • Transient Response
    Step Load : ±350 to 450 mV pk, Step Line : ±250 to 600 mV pk
  • Weight
    86 g
  • Storage Temperature
    -65 to 150 Degree C
