Single Output DC to DC Converter from 3.23 to 3.37 V

SKU: SMFLHP283R3S

Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

SMFLHP283R3S Image

The SMFLHP283R3S from Crane Aerospace & Electronics is a DC to DC Converter with Input Voltage 19 to 40 V, Output Voltage 1 3.23 to 3.37 V, Output Current 1 0 to 16 A, Output Power 0 to 53 W, Power Consumption 15 to 24 W (Dissipation). Tags: Surface Mount. More details for SMFLHP283R3S can be seen below.

Product Specifications

Product Details

  • Part Number
    SMFLHP283R3S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    Single Output DC to DC Converter from 3.23 to 3.37 V

General Parameters

  • Segment
    Ground
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    19 to 40 V
  • Output Voltage 1
    3.23 to 3.37 V
  • Output Current 1
    0 to 16 A
  • Output Power
    0 to 53 W
  • Power Consumption
    15 to 24 W (Dissipation)
  • Efficiency
    65 to 72%
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Surface Mount
  • Application
    Space
  • Dimension
    3.005 x 1.505 x 0.4 Inches
  • Capacitance
    1000 uF
  • Frequency
    525 to 675 kHz
  • Number of Outputs
    Single
  • Regulation
    Line : 0 to 50 mV, Load : 0 to 20 mV
  • Ripple Voltage
    10 to 40 mVpp
  • Transient Response
    Step Load : ±350 to 400 mV pk, Step Line : ±250 to 400 mV pk
  • Weight
    86 g
  • Storage Temperature
    -65 to 150 Degree C
