11.76 to 12.24 V Single Output DC to DC Converter

SKU: SMRT2812S

Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

SMRT2812S Image

The SMRT2812S from Crane Aerospace & Electronics is a DC to DC Converter with Input Voltage 19 to 56 V, Output Voltage 1 11.76 to 12.24 V, Output Current 1 2.92 A, Output Power 35 W, Power Consumption 20 W (Dissipation). Tags: Surface Mount. More details for SMRT2812S can be seen below.

Product Specifications

Product Details

  • Part Number
    SMRT2812S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    11.76 to 12.24 V Single Output DC to DC Converter

General Parameters

  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    19 to 56 V
  • Output Voltage 1
    11.76 to 12.24 V
  • Output Current 1
    2.92 A
  • Output Power
    35 W
  • Power Consumption
    20 W (Dissipation)
  • Efficiency
    75 to 78%
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Surface Mount
  • Application
    Space
  • Capacitance
    5000 uF
  • Frequency
    270 to 330 kHz
  • Number of Outputs
    Single
  • Regulation
    Line : 5 to 30 mV, Load : 5 to 40 mV
  • Ripple Voltage
    160 to 200 mVpp
  • Transient Response
    Step Load : ±575 mV pk, Step Line : ±700 mV pk
  • Weight
    100 g
  • Storage Temperature
    -65 to 150 Degree C
