Dual Output DC to DC Converter from 14.7 to 15.3 V

SKU: SMRT2815D

Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

SMRT2815D Image

The SMRT2815D from Crane Aerospace & Electronics is a DC to DC Converter with Input Voltage 19 to 56 V, Output Voltage 1 14.7 to 15.3 V, Output Current 1 1.17 A, Output Power 17.5 W, Power Consumption 20 W (Dissipation). Tags: Surface Mount. More details for SMRT2815D can be seen below.

Product Specifications

Product Details

  • Part Number
    SMRT2815D
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    Dual Output DC to DC Converter from 14.7 to 15.3 V

General Parameters

  • Configuration
    Isolated
  • Number of Output
    Dual
  • Input Voltage
    19 to 56 V
  • Output Voltage 1
    14.7 to 15.3 V
  • Output Current 1
    1.17 A
  • Output Power
    17.5 W
  • Power Consumption
    20 W (Dissipation)
  • Efficiency
    75 to 80%
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Surface Mount
  • Application
    Space
  • Capacitance
    5000 uF
  • Frequency
    270 to 330 kHz
  • Number of Outputs
    Dual
  • Regulation
    Line : 5 to 30 mV, Load : 5 to 40 mV
  • Ripple Voltage
    140 to 180 mVpp
  • Transient Response
    Step Load : ±575 mV pk, Step Line : ±700 mV pk
  • Weight
    100 g
  • Storage Temperature
    -65 to 150 Degree C
