23 W Single Output DC to DC Converter from 3.23 to 3.37 V

SKU: SMRT283R3S

Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

SMRT283R3S Image

The SMRT283R3S from Crane Aerospace & Electronics is a DC to DC Converter with Input Voltage 19 to 56 V, Output Voltage 1 3.23 to 3.37 V, Output Current 1 6.97 A, Output Power 23 W, Power Consumption 31 W (Dissipation). Tags: Surface Mount. More details for SMRT283R3S can be seen below.

Product Specifications

Product Details

  • Part Number
    SMRT283R3S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    23 W Single Output DC to DC Converter from 3.23 to 3.37 V

General Parameters

  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    19 to 56 V
  • Output Voltage 1
    3.23 to 3.37 V
  • Output Current 1
    6.97 A
  • Output Power
    23 W
  • Power Consumption
    31 W (Dissipation)
  • Efficiency
    60 to 64%
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Surface Mount
  • Application
    Space
  • Capacitance
    5000 uF
  • Frequency
    270 to 330 kHz
  • Number of Outputs
    Single
  • Regulation
    Line : 5 to 30 mV, Load : 5 to 40 mV
  • Ripple Voltage
    250 to 280 mVpp
  • Transient Response
    Step Load : ±450 mV pk, Step Line : ±500 mV pk
  • Weight
    100 g
  • Storage Temperature
    -65 to 150 Degree C
