Single Output Isolated DC to DC Converter from 11.64 to 12.36 V

SKU: SMSA2812S

Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

SMSA2812S Image

The SMSA2812S from Crane Aerospace & Electronics is a DC to DC Converter with Input Voltage 16 to 40 V, Output Voltage 1 11.64 to 12.36 V, Output Current 1 0.417 A, Output Power 5 W, Power Consumption 1.2 to 2.1 W (Dissipation). Tags: Surface Mount. More details for SMSA2812S can be seen below.

Product Specifications

Product Details

  • Part Number
    SMSA2812S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    Single Output Isolated DC to DC Converter from 11.64 to 12.36 V

General Parameters

  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    16 to 40 V
  • Output Voltage 1
    11.64 to 12.36 V
  • Output Current 1
    0.417 A
  • Output Power
    5 W
  • Power Consumption
    1.2 to 2.1 W (Dissipation)
  • Efficiency
    68 to 74%
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Surface Mount
  • Application
    Space
  • Capacitance
    500 uF
  • Frequency
    400 to 600 kHz
  • Number of Outputs
    Single
  • Regulation
    Line : 10 to 50 mV, Load : 10 to 50 mV
  • Ripple Voltage
    125 to 300 mVpp
  • Transient Response
    Step Load : ±300 to 400 mV pk, Step Line : -1000 to 800 mV pk
  • Weight
    15 g
  • Storage Temperature
    -65 to 150 Degree C
