Single Output DC to DC Converter from 3.15 to 3.45 V

SKU: SMSA283R3S

DC to DC Converter by Crane Aerospace & Electronics
116 more products
Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

SMSA283R3S Image

The SMSA283R3S from Crane Aerospace & Electronics is a DC to DC Converter with Input Voltage 16 to 40 V, Output Voltage 1 3.15 to 3.45 V, Output Current 1 0 to 1.2 A, Output Power 4 W, Power Consumption 1.5 to 2.5 W (Dissipation). Tags: Surface Mount. More details for SMSA283R3S can be seen below.

Product Specifications

Product Details

  • Part Number
    SMSA283R3S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    Single Output DC to DC Converter from 3.15 to 3.45 V

General Parameters

  • Segment
    Satellite
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    16 to 40 V
  • Output Voltage 1
    3.15 to 3.45 V
  • Output Current 1
    0 to 1.2 A
  • Output Power
    4 W
  • Power Consumption
    1.5 to 2.5 W (Dissipation)
  • Efficiency
    60%
  • Operating Temperature
    -55 to 125 Degree C
  • Industry
    Space
  • Package Type
    Surface Mount
  • Application
    Space
  • Capacitance
    500 uF
  • Frequency
    400 to 600 kHz
  • Number of Outputs
    Single
  • Regulation
    Line : 10 to 50 mV, Load : 10 to 50 mV
  • Space Standard
    MIL-STD-883, MIL-PRF-38534
  • Standard
    MIL-PRF-38534 Class K, MIL-PRF-38534 Class H
  • Ripple Voltage
    300 to 900 mVpp
  • Transient Response
    Step Load : ±200 to 500 mV pk, Step Line : ±200 to 500 mV pk
  • Weight
    15 g
  • Storage Temperature
    -65 to 150 Degree C
