Dual Output DC to DC Converter from 14.47 to 15.53 V

SKU: SMTR2815D

Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

SMTR2815D Image

The SMTR2815D from Crane Aerospace & Electronics is a DC to DC Converter with Input Voltage 16 to 40 V, Output Voltage 1 14.47 to 15.53 V, Output Current 1 0 to 2 A, Output Power 0 to 30 W, Power Consumption 5 to 12 W (Dissipation). Tags: Surface Mount. More details for SMTR2815D can be seen below.

Product Specifications

Product Details

  • Part Number
    SMTR2815D
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    Dual Output DC to DC Converter from 14.47 to 15.53 V

General Parameters

  • Configuration
    Isolated
  • Number of Output
    Dual
  • Input Voltage
    16 to 40 V
  • Output Voltage 1
    14.47 to 15.53 V
  • Output Current 1
    0 to 2 A
  • Output Power
    0 to 30 W
  • Power Consumption
    5 to 12 W (Dissipation)
  • Efficiency
    75 to 81%
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Surface Mount
  • Application
    Space
  • Capacitance
    1500 uF
  • Frequency
    550 to 650 kHz
  • Number of Outputs
    Dual
  • Regulation
    Line : 0 to 180 mV, Load : 50 to 180 mV
  • Ripple Voltage
    25 to 120 mVpp
  • Transient Response
    Step Load : ±220 to 400 mV pk, Step Line : ±500 mV pk
  • Weight
    50 g
  • Storage Temperature
    -65 to 150 Degree C
