Single Output DC to DC Converter from 3.201 to 3.399 V

SKU: SMTR283R3S

Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

SMTR283R3S Image

The SMTR283R3S from Crane Aerospace & Electronics is a DC to DC Converter with Input Voltage 16 to 40 V, Output Voltage 1 3.201 to 3.399 V, Output Current 1 0 to 5.45 A, Output Power 18 W, Power Consumption 12 W (Dissipation). Tags: Surface Mount. More details for SMTR283R3S can be seen below.

Product Specifications

Product Details

  • Part Number
    SMTR283R3S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    Single Output DC to DC Converter from 3.201 to 3.399 V

General Parameters

  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    16 to 40 V
  • Output Voltage 1
    3.201 to 3.399 V
  • Output Current 1
    0 to 5.45 A
  • Output Power
    18 W
  • Power Consumption
    12 W (Dissipation)
  • Efficiency
    66 to 73%
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Surface Mount
  • Application
    Space
  • Capacitance
    3000 uF
  • Frequency
    550 to 650 kHz
  • Number of Outputs
    Single
  • Regulation
    Line : 0 to 20 mV, Load : 2 to 20 mV
  • Ripple Voltage
    20 to 50 mVpp
  • Transient Response
    Step Load : ±130 to 300 mV pk, Step Line : ±300 mV pk
  • Weight
    50 g
  • Storage Temperature
    -65 to 150 Degree C
