16.5 W DC – DC Converter from 3.1 to 3.4 V

SKU: 3813-S3.3

DC to DC Converter by Modular Devices
411 more products
Download Datasheet Request Information

Note : Your request will be directed to Modular Devices.

3813-S3.3 Image

The 3813-S3.3 from Modular Devices is a DC to DC Converter with Input Voltage 18 to 50 V, Output Voltage 1 3.1 to 3.4 V, Output Current 1 0.5 to 5 A, Output Power 16500 mW, Isolation Voltage 500 Vdc. Tags: Through Hole. More details for 3813-S3.3 can be seen below.

Product Specifications

Product Details

  • Part Number
    3813-S3.3
  • Manufacturer
    Modular Devices
  • Description
    16.5 W DC – DC Converter from 3.1 to 3.4 V

General Parameters

  • Segment
    Satellite
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    18 to 50 V
  • Output Voltage 1
    3.1 to 3.4 V
  • Output Current 1
    0.5 to 5 A
  • Output Power
    16500 mW
  • Isolation Voltage
    500 Vdc
  • Efficiency
    67 to 70%
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Through Hole
  • Application
    Space
  • Frequency
    200 kHz
  • Number of Outputs
    Single
  • Regulation
    Line : 100 to 200 mV, Load : 100 to 200 mV
  • Space Standard
    MIL-STD-810, MIL-STD-883
  • Ripple Voltage
    30 to 100 mVpp
  • Weight
    35 g
  • Storage Temperature
    -55 to 150 Degree C
