2.5 W Single output DC-DC Converter from 11.9 to 12.1 V

SKU: 4690-S12

DC to DC Converter by Modular Devices
411 more products
Download Datasheet Request Information

Note : Your request will be directed to Modular Devices.

4690-S12 Image

The 4690-S12 from Modular Devices is a DC to DC Converter with Input Voltage 16 to 50 V, Output Voltage 1 11.9 to 12.1 V, Output Current 1 0.0208 to 0.208 A, Output Power 2500 mW, Isolation Voltage 100 to 500 Vdc. Tags: Through Hole, Module. More details for 4690-S12 can be seen below.

Product Specifications

Product Details

  • Part Number
    4690-S12
  • Manufacturer
    Modular Devices
  • Description
    2.5 W Single output DC-DC Converter from 11.9 to 12.1 V

General Parameters

  • Segment
    Satellite
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    16 to 50 V
  • Output Voltage 1
    11.9 to 12.1 V
  • Output Current 1
    0.0208 to 0.208 A
  • Output Power
    2500 mW
  • Isolation Voltage
    100 to 500 Vdc
  • Efficiency
    81 to 85%
  • Package Type
    Through Hole, Module
  • Application
    Space
  • Frequency
    200 kHz
  • Number of Outputs
    Single
  • Regulation
    Line : 20 to 100 mV, Load : 250 to 500 mV
  • Space Standard
    MIL-STD-461C
  • Standard
    MIL-STD-461C CE01, CE03, CS01, CS02 and CS06
  • Ripple Voltage
    60 to 150 mVpp
  • Weight
    50 g
  • Storage Temperature
    -55 to 150 Degree C
