High Power Limiter from DC to 40 GHz

SKU: HLM-40PSM

Power Limiter by Marki Microwave
8 more products
Download Datasheet Request Information

Note : Your request will be directed to Marki Microwave.

The HLM-40PSM from Marki Microwave is a Power Limiter with Frequency DC to 40 GHz, Input Power P1 dB 14 dBm, Peak Input Power 39.78 dBm, Peak Input Power 9.5 W, Limited Output Power 33.98 dBm. Tags: Surface Mount, Schottky Diode. More details for HLM-40PSM can be seen below.

Product Specifications

Product Details

  • Part Number
    HLM-40PSM
  • Manufacturer
    Marki Microwave
  • Description
    High Power Limiter from DC to 40 GHz

General Parameters

  • Type
    Schottky Diode
  • Technology
    GaAs
  • Frequency
    DC to 40 GHz
  • Input Power P1 dB
    14 dBm
  • Peak Input Power
    39.78 dBm
  • Peak Input Power
    9.5 W
  • Limited Output Power
    33.98 dBm
  • Limited Output Power
    2.5 W
  • Insertion Loss
    0.5 to 1.75 dB
  • CW Flat Leakage
    11 to 19 dBm
  • RoHS Compliant
    Yes
  • Recovery Time
    8 ns
  • Package Type
    Surface Mount
  • Return Loss
    17 dB
  • Operating Temperature
    -55 to 100 Degree C
  • Storage Temperature
    -65 to 125 Degree C
  • Weight
    0.041 g
  • Dimension
    4 x 4 mm
  • Application
    RF Transceivers, Test & Measurement, SATCOM, Ka Band, Equipment
  • Note
    Spike Leakage : 0.1 erg
