6 to 18 GHz Positive Gain-Slope Amplifier

SKU: CMX90G701

Note : Your request will be directed to CML Microcircuits.

CMX90G701 Image

The CMX90G701 from CML Microcircuits is a RF Amplifier with Frequency 6 to 18 GHz, Small Signal Gain 9.4 to 10.4 dB, Noise Figure 2.6 dB, P1dB 0.01 W, IP3 19 dBm. Tags: Surface Mount, Power Amplifier, Gain Block Amplifier. More details for CMX90G701 can be seen below.

Product Specifications

Product Details

  • Part Number
    CMX90G701
  • Manufacturer
    CML Microcircuits
  • Description
    6 to 18 GHz Positive Gain-Slope Amplifier

General Parameters

  • Type
    Power Amplifier, Gain Block Amplifier
  • Configuration
    IC/MMIC/SMT
  • Application
    Fixed Wireless Access (FWA), PA Modules
  • Frequency
    6 to 18 GHz
  • Small Signal Gain
    9.4 to 10.4 dB
  • Noise Figure
    2.6 dB
  • P1dB
    0.01 W
  • IP3
    19 dBm
  • IP3
    0.08 W
  • Input Power
    12 dBm
  • Input Power
    0.015 W
  • Impedance
    50 Ohms
  • Reverse Isolation
    16 dB
  • Return Loss
    10 dB
  • Input Return Loss
    10 dB
  • Output Return Loss
    10 dB
  • Supply Voltage
    5.5 V
  • Current Consumption
    22 mA
  • Transistor Technology
    pHEMT
  • Technology
    GaAs
  • Package Type
    Surface Mount
  • Package
    3x3mm VQFN-16
  • Dimensions
    3 x 3 mm
  • Space Qualified
    Yes
  • Operating Temperature
    -40 to 85 Degree C
  • Storage Temperature
    -40 to 125 Degree C
  • RoHS
    Yes
