26-35 GHz (K, Ka, Q Band) Balanced Driver Amplifier MMIC

SKU: CMD199

RF Amplifier by Qorvo
7 more products
Request Information

Note : Your request will be directed to Qorvo.

CMD199 Image

The CMD199 from Qorvo is a RF Amplifier with Frequency 26 to 35 GHz, Gain 15 dB, Noise Figure 3.5 dB, P1dB 0.089 W, IP3 24.5 dBm. Tags: Driver Amplifier. More details for CMD199 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    CMD199
  • Manufacturer
    Qorvo
  • Description
    26-35 GHz (K, Ka, Q Band) Balanced Driver Amplifier MMIC

General Parameters

  • Type
    Driver Amplifier
  • Configuration
    Die
  • Frequency
    26 to 35 GHz
  • Gain
    15 dB
  • Noise Figure
    3.5 dB
  • P1dB
    0.089 W
  • IP3
    24.5 dBm
  • IP3
    0.28 W
  • Grade
    Space Qualified
  • Saturated Power
    0.141 W
  • Industry Application
    Space, Aerospace & Defense, Military
  • Impedance
    50 Ohms
  • Input Return Loss
    14 dB
  • Output Return Loss
    20 dB
  • P1dB
    19.5 dBm
  • Supply Voltage
    5 V
  • Current Consumption
    72 mA
  • Technology
    GaAs
  • Pulsed/CW
    CW
  • Saturated Power
    21.5 dBm
  • RoHS
    Yes
  • Standards Supported
    K Band, Ka Band, Q Band
