0.4 to 2.2 GHz Low Noise Monolithic Amplifier

SKU: CMA-545G1+

RF Amplifier by Mini Circuits (7 more products)

Note : Your request will be directed to Mini Circuits.

CMA-545G1+ Image

The CMA-545G1+ from Mini-Circuits is a Space-Qualified Low Noise Amplifier that operates from 400 MHz-2.2 GHz. It has a high gain of 32 dB and an ultra-low noise figure of 0.8 dB. This low-noise monolithic amplifier has a high IP3 of 36 dBm and a high Pout, P1dB up to 22 dBm. It requires a DC supply of 6 V and has a DC current of 158 mA. This E-PHEMT-based amplifier enables it to work with a single positive supply voltage. It is unconditionally stable over the operating frequency. It has a terminal finish of Ni-Pd-Au and has repeatable performance from lot to lot due to fully automated, tightly controlled semiconductor and assembly processes. This RoHS-compliant amplifier measures 3 x 3 x 1.14 mm and is ideal for cellular, ISM, GSM, WCDMA, LTE, and GPS applications.

Product Specifications

Product Details

  • Part Number
    CMA-545G1+
  • Manufacturer
    Mini Circuits
  • Description
    0.4 to 2.2 GHz Low Noise Monolithic Amplifier

General Parameters

  • Type
    Low Noise Amplifier
  • Configuration
    IC/MMIC/SMT
  • Frequency
    400 MHz to 2.2 GHz
  • Gain
    28.1 to 34.5 dB
  • Noise Figure
    0.8 to 1.2 dB
  • Output Power
    20 to 23.3 dBm
  • P1dB
    0.21 to 0.21 W
  • IP3
    36.5 dBm
  • IP3
    4.47 W
  • Input Power
    25 dBm
  • Input Power
    0.316 W
  • Impedance
    50 Ohms
  • Input VSWR
    1.90:1
  • Output VSWR
    1.40:1
  • Input Return Loss
    9.1 to 16.5 dB
  • Output Return Loss
    14.2 to 21.5 dB
  • Supply Voltage
    4.8 to 5.2 V
  • Current Consumption
    158 mA
  • Transistor Technology
    E-PHEMT
  • Package Type
    Surface Mount
  • Space Qualified
    On Request
  • RoHS
    Yes
